AVG Non Return Isolation Duo Valve NRIBV-15C 15mm 1/2" Compression Fitting

NRIBV-15C

Non Return , Isolating Valves

The NRIBV range of non return isolation valves (NRI) combine the non-return and isolating functions in one simple campact valve. The NRIBV range is available in 15mm and 20mm and with optional female, flare and nut and copper olive compression ends.

The NRIBVS range of non return isolating valves incorporate a line strainer which is designed to protect any down stream valves and or equipment. The removable strainer prevents grit and debris from entering the line.

Features

• Suitable for horizontal or vertical installation
• Forged DR brass body
• Complies with AS1357.1
• Watermark Certification
• Easily visible on or off quarter turn handle
• Removable strainer for cleaning

Specification Sheet

NRI Specifications

Model	DN Size	Inlet/Outlet	Overall Length
NRIBV-15-C	15	15 (1/2”) Compression	79mm
NRIBV-15-F	15	15 (1/2”) Female	64mm
NRIBV-15-INV	15	15 (1/2”) Flare	86mm
NRIBVS-15F	15	15 (1/2”) Female	85mm
NRIBVS-20F	15	20 (3/4”) Female	95mm
NRIBVS-20C	15	20 (3/4”) Male	135mm
